| Tipi | Kod Numarası | Plaka Genişliği
A | Ağırlık | Kalınlığı | Yana Büküm | Geri Bükülme
| Taşıma Kapasitesi (max.) |
| | | mm | inc | kg/m | mm | mm | (R) | N (21°C) |
| XL-ASETAL |
| LF 880-K325 L | L0880603981 | 82.5 | 3.25 | 0.89 | 4.0 | 457 | 40 | 2100 |
| LF 880-K450 | L0880603991 | 114.3 | 4.50 | 1.04 | 4.0 | 457 | 40 | 2100 |
| WX-POLYAMİD ALAŞIM |
| WX 880-K325 | L0880603991 | 82.5 | 3.25 | 0.89 | 4.0 | 457 | 40 | 2100 |
| WX 880-K450 L | L0880616002 | 114.3 | 4.50 | 1.04 | 4.0 | 457 | 40 | 2100 |
 |
| Tipi | Kod Numarası | Plaka Genişliği
A | Ağırlık | Kalınlığı | Yana Büküm | Geri Bükülme
| Taşıma Kapasitesi (max.) |
| | | mm | inc | kg/m | mm | mm | (R) | N (21°C) |
| LF-ASETAL |
| LF 879-K325 | LF879K3-1/4 | 83.8 | 3.25 | 0.89 | 4.8 | 457 | 40 | 2100 |
| LF 879-K450 | LF879K4-1/2 | 114.3 | 4.50 | 1.04 | 4.8 | 457 | 40 | 2100 |
| WX-POLYAMİD ALAŞIM |
| WX 879-K450 | 81428412 | 114.3 | 4.50 | 1.04 | 4.8 | 457 | 40 | 2100 |
 |
| Tipi | Kod Numarası | Plaka Genişliği
A | Ağırlık | Kalınlığı | Yana Büküm | Geri Bükülme
| Taşıma Kapasitesi (max.) |
| | | mm | inc | kg/m | mm | mm | (R) | N (21°C) |
| XL-ASETAL |
| RH 350 XL | 751.42.31 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 50 | 2100 |
| RH 450 XL | 751.42.42 | 114.3 | 4.50 | 1.08 | 4.0 | 457 | 50 | 2100 |
| LF-ASETAL |
| LF 880 TAB-K325 | L0880604031 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| LF 880 TAB-K325 plastic pin* | L0880632221 | 82.5 | 3.25 | 0.74 | 4.0 | 457 | 40 | 1050 |
| LF 880 TAB-K325 non-magnetic pin** | L0880683712 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| LF 880 TAB-K343 | L0880667941 | 87.0 | 3.43 | 1.01 | 4.0 | 500 | 40 | 2100 |
| LF 880 TAB-K350 | L0880641151 | 88.9 | 3.50 | 1.01 | 4.0 | 500 | 40 | 2100 |
| LF 880 TAB-K450 | L0880604041 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| LF 880 TAB-K450 plastic pin* | L0880648371 | 114.3 | 4.50 | 0.91 | 4.0 | 500 | 40 | 1050 |
| LF 880 TAB-K450 non-magnetic pin** | L0880605273 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| PS-ASETAL |
| RH 325 PS | 751.10.03 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| PS 880 TAB-K325 | L0880606723 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| PS 880 TAB-K325 non-magnetic pin** | L0880612863 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| PS 880 TAB-K343 | L0880616043 | 87.0 | 3.43 | 1.01 | 4.0 | 500 | 40 | 2100 |
| PS 880 TAB-K450 | L0880608503 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| PS 880 TAB-K450 non-magnetic pin** | L0880620573 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| WX-POLYAMİD ALAŞIM |
| WX 880 TAB-K325 | L0880613512 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| WX 880 TAB-K450 L | L0880639662 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| HP-ASETAL |
| HP 880 TAB-K325 L | L0880613141 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| HP 880 TAB-K325 non-magnetic pin** | L0880613093 | 82.5 | 3.25 | 0.94 | 4.0 | 457 | 40 | 2100 |
| HP 880 TAB-K450 L | L0880613151 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
| HP 880 TAB-K450 non-magnetic pin** | L0880620563 | 114.3 | 4.50 | 1.08 | 4.0 | 500 | 40 | 2100 |
 |
| Tipi | Kod Numarası | Plaka Genişliği
A | Ağırlık | Kalınlığı | Yana Büküm | Geri Bükülme
| Taşıma Kapasitesi (max.) |
| | | mm | inc | kg/m | mm | mm | (R) | N (21°C) |
| XL-ASETAL |
| RHD 325 XL | 751.62.31 | 82.5 | 3.25 | 0.98 | 4.8 | 457 | 50 | 2100 |
| RHD450 XL | 751.62.42 | 114.3 | 4.50 | 1.14 | 4.8 | 610 | 50 | 2100 |
| LF-ASETAL |
| LF 879 TAB-K325 | L0879604071 | 82.5 | 3.25 | 0.98 | 4.8 | 457 | 40 | 2100 |
| LF 879 TAB-K450 | L0879604081 | 114.3 | 4.50 | 1.14 | 4.8 | 610 | 40 | 1050 |
| WX-POLYAMİD ALAŞIM |
| WX 879 TAB-K450 | L0879676002 | 114.3 | 4.50 | 1.14 | 4.8 | 610 | 40 | 2100 |
|
